Technical data
Housing
- Protection rating (EN 60529)
-
- IP50
- Dial
-
- White, Aluminium
- Pointer
-
- Black, Aluminium
- Window material
-
- Instrument glass
- Nominal size
-
- 100 mm
- Case material
-
- Stainless steel 1.4301 / AISI 304
- Bezel ring material
-
- Stainless steel 1.4301 / AISI 304
Temperature
- Temperature range
-
- -20°C … +250°C
Wetted parts
- Immersion tube material
-
- Brass
- Stainless steel 1.4571 / AISI 316Ti
- Minimum immersion length
-
- 10 ± 2 mm
Performance
- Accuracy according to EN 13190
-
- Class 1
Weight
- Thermometer
-
- 180 g
