OR18.TI-ZZZZ.71OV/0010

OR18.TI-ZZZZ.71OV/0010

Ajánlatkérés
PDF letöltése
Cikkszám: 11157825 Kategóriák: , ,

Leírás

Technical data
General data

Type
  • Through beam sensor
Emitter / receiver
  • Emitter
Light source
  • Pulsed infrared diode
Actual range Sb
  • 13 m
Nominal range Sn
  • 20 m
Power on indication
  • LED green
Emission power adjustment
  • No
Wave length
  • 880 nm
Electrical data

Voltage supply range +Vs
  • 12 … 30 VDC
Current consumption max. (no load)
  • 40 mA
Current consumption typ.
  • 30 mA
Reverse polarity protection
  • Yes
Mechanical data

Width / diameter
  • 18 mm
Height / length
  • 44.8 mm
Design
  • Cylindrical threaded
Housing material
  • Plastic (ABS TERLURAN)
Front (optics)
  • PMMA
Connection types
  • Flylead connector M12 4 pin, L=100 mm
Ambient conditions

Operating temperature
  • -25 … +55 °C
Protection class
  • IP 67
